1. Extruder: 1 set
(1) Screw diameter: 90mm, Rotation speed of screw: 0～72rpm.
(2) L:D: 33:1, Material of screw: 38CrMoALA ,
the screw is suitable for PP+PE Virgin.
(3) Filter: Auto screen changer.
(4) Pressure feedback system can adjust the screw speed automatically.
(5) Material of barrel heater: Far infraed
(6) Metering pump, rotation speed: 0-45 rotation.
(7) Electrical heating round spinneret: 1 set
(8) Spinneret heater: by ceramic heating rings with SS insulating layer.
(9) Spinneret plate: 2 pieces

2. Cold water tank: 1 set
(1) The tank is made by SS 304.
(2) Pushed and pulled in side way, the automatic lifting of tank.
(3) Special designed roller guider to separate the yarn in the tank easily.

3. Dryer system:1 set

4. First 7-unit roller system:1 set
(1) Five variable diameter rollers and two steel rollers.
(2) Max drafting force: 1000 daN.
(3) Steel box with accurately grind gear makes the rollers run smoothly.
(4) Built-out oil lubrication system which makes the gears runs steady.
The bearings are from TIMKEN-TWB.

5. First Double-layer hot oven tank:1 set
(1) Heating power: 23KW
(2) Oven length: 5000 mm
(3) Special design of hot air channel which make the temperature evenly.

6.Second 7-unit roller system:1 set
(1) Seven variable diameter rollers with hard chrome plating.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady.

7. Winding machine
(1) Bobbin size as client’s reqeust.

8. Actual running power: 115KW
