1. Extruder: 1 set
(1) Automatic screw type loading machine: 1 set
(2) Screw diameter: Φ100MM
(3) Screw L/D:1:33
(4) Screw material: 38GrMoAl and alloy plating on the surface of screw.
(5) Max. output: 300KG/H(Depending upon tape characteristics and material)
(6) Barrel heating use cast aluminum heating band, Solid relay control the heating and equip the cooling fan.
(7) Die use inlay stainless steel heating pipe, Solid relay control the heating
(8) Die length: 1300MM
(9) Metering pump:1 set
(10) Drive power of metering pump:11kw
(11) Filter changer: Automatic double belt changer.

2. Cold water tank: 1 set
(1) Material: Stainless steel 304.
(2) Up and down adjustable

3. Filter lifting and dry system: 1 set
(1) Water removal plate: 2 sets
(2) Squeeze device: 1 set
(3) Lifting device: 1 set,
(4) Suction device: 2 sets

4. Dryer system: 1 set
(1) Material of cutter shaft: Aluminum
(2) The cutter shaft can be adjusted up and down and around.

5. First 5-unit roller system:1 set
(1) Outside diameter of roller: 180mm (Bearing: TWB)
(2) Motor power: 5.5kw
(3) Max linear speed: 40m/min.
(4) Edge-film crushing recycling system: 1 set
Fan power: 2.2KW×2 sets

6. Double-layer hot oven tank: 1 set
(1) Oven length: 6000MM
(2) Oven width: 1600MM
(3) Heating power: 80kw
(4) Fan power: 5.5KW×2 sets
(5) Inner heating pipe, SCR temperature controller.
(6) Static eliminator: One set

7. Second 5-unit roller system:1 set
(1) Roller size: Φ415MMx1350MM (bearing: TWB)
(2) Two cooling rollers, Two heating roller and one rubber pressuring roller.
(3) Roller treatment: Hard chromium plating and mirror treatment on the surface.
Equip European standard safety protective shield.
(4) Motor power: 15KW x 2 sets
(5) Needle roller: 1 set for fibrillated.
(6) Max linear speed: 150m/min
(7) Motor power: 7.5kw

8. First 2-roller setting system: 1 set
(1) Roller size: Φ415MMx1350MM
(2) Two heating roller.
(3) Motor power: 5.5kw
(4) Max linear speed: 150m/min.

7. Second 2-roller setting system: 1 set
(1) Roller size: Φ415MMx1350MM
(2) Two heating roller.
(3) Motor power: 5.5kw
(4) Max linear speed: 150m/min.

8. Third 2-roller setting system: 1 set
(1) Roller size: Φ415MMx1350MM
(2) Two heating roller.
(3) Motor power: 5.5kw
(4) Max linear speed: 150m/min.

9. 80 spindles winding machine
(1) Wind top line speed: 150m/min
(2) Single spindle power of electric generator

10. Waster yarn collectors system: 1 set
(1) Motor power: 11Kw

11. Total weight : 30T.
