1. Extruder: 1 set
(1) Screw dia.: 90mm; Rotation speed: 0～100rpm,
(2) L:D: 30:1; Material of screw: 38CrMoALA;
(3) Pressure automatic feedback system.
(4) Melt filter: Double position melt filter changer
(5) Spinneret device: 2 sets
(6) Metering pump:2 sets
(7) Heater: Electric heating ring

2. Cold water tank: 1 set
(1) The tank is made by Stainless Steel 304.
(2) The height of tank is adjustable and the horizontal pushing structure.

3. First 7-unit roller system:1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Steel cabinet with accurately grind gear.

4. Hot water Tank:1 set
(1) Heating power: 50KW; Electrical heating.
(2) Material is stainless steel 304 with heat preservation.

5. Second 7-unit roller system:1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Steel cabinet with accurately grind gear.

6. winding machine:1 set
(1) Winding spool
