1. Extruder: 1 set
(1) Screw diameter: 80mm, Rotation speed of screw: 0～72 rpm.
(2) L:D: 30:1, Material of screw: 38CrMoALA ,
(3) Pressure feedback system.
(4) Material of barrel heater: Far infarad
(5) Metering pump 30cc*2 sets, rotation speed: 0-45 rotation.
(6) Oil heating round spinneret: 2 sets.

2. Cold water tank: 1 set
(1) The tank is made by SS 304.

3. First 7-unit roller system:1 set
(1) Seven variable diameter rollers which made by stainless steel 304.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Built-out oil lubrication system which makes the gears runs steady.
(4) Equip 1 pressing roller.

5. Overflow type hot water tank:1 set
(1) Tank size: 4000mm
(2) Heating power: 50KW,
(3) The tank is made by SS 304
(4) Water removal device: 2 sets
(5) Water circulating water pump 2 sets

6. Second 7-unit roller system:1 set
(1) Seven variable diameter rollers which made by steel pipe.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady.

7. First single-layer hot oven tank:1 set
(1) Oven length: 4300 mm

8. Third 7-unit roller system:1 set
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady.

9. Second single-layer hot oven tank:1 set
(1) Oven length: 4300 mm

10. Fourth 7-unit roller system:1 set
(1) Seven variable diameter rollers which made by steel pipes.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady.

11. Oil system: 1 set
(1) Frequency control of speed

12. 216 spindles winding machine
(1) Spool and bobbin are as client’s reqeust
(2) The frame transmission is frequency control, driving motor: 2.2kw
(3) Winding motor: 5KG

13. Waster yarn collectors: 2 sets
