1.80×33 Extruder: 1 set
(1) Screw diameter: 80mm, Rotation speed of screw: 0～72 rpm.
(2) L:D: 33:1, Material of screw: 38CrMoALA;
(3) Automatic screen changer:1 set
(4) Pressure feedback system.
(5) Material of barrel heater: Far infarad
(6) Electric heating round spinneret: 1 set
(7) Ceramic heating rings for spinneret with SS insulating layer make the heat evenly.
(8) Spinneret components with disassembly support.
(9) Metering pump, Frequency control of metering pump speed, driving power: 4KW.

2.Cold water tank: 1 set
(1) The tank is made by SS 304.
(2) Material of distributing roller

3. First 7-unit roller system:1 set
(1)Seven viable diameter rollers, there are five rollers are covered with rubber to resist skidding.
(2) Steel structure box with accurately grind gear.
(3) Built-out oil lubrication system which makes the gears runs steady.

4.Hot water tank:1 set
(1) Heating power: 27kw, two zones heater.
(2) Double pressure rollers with twin cylinder opening system.
(3) Water suction.

5. Second 7-unit roller system:1 set
(1) Seven variable diameter rollers with hard chrome plating.
(2) Steel structure box with accurately grind gear.
(3) Built-in oil lubrication system which makes the gears runs steady.

6. Single- layer hot oven tank: 1 set
(1) Fan power: 2.2KW×2 sets
(2) Heating power: 23KW
(3) Oven length: 5000 mm

7.Third 7-unit roller system:1 set
(1) Seven variable diameter rollers with hard chrome plating.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.

8. 4 sets, 8 spindles winding machine
1)Motor: 150kg torque motor

Total installation power: 180KW

Overall size: 40000×1800×2500mm
