1. Extruder: 1 set
(1) Screw dia.: 85mm; Rotation speed: 0～80rpm,
(2) L:D: 30:1; The screw is special design for Polyethylene material.
(3) Pressure feedback system can adjust the screw speed automatically.
(4) Spinneret device: 1 set
(5) Metering pump: 1 set
(6) Color doserm: 1 set
(7) Magnet device: 1 set

2. Cold water tank: 1 set
(1) The tank is made by Stainless Steel 304.
(2) The horizontal pushing structure is conveniently to disassembly the spinneret.

3. First 7-unit roller system:1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-out oil lubrication system makes gears run steady.
(3) Max drafting force: 1000 daN.

4. Hot water Tank:1 set
(1) Heating power: 70KW; Electrical heating, copper heating pipe
(2) Equip two pressing roller .

5. Second 7-unit roller system:1 set
(1) Seven pieces variable diameter roller with hard chrome plating.
(2) Built-in oil lubrication system which makes the gears run steady.
(3) Max drafting force: 1000 daN.

6. Winding machine
(1) Winding bobbin as per clinet’s reqeust.
(2) Tesnion control by inverter.
