1. Extruder: 2sets
(1) Screw diameter: 70mm.
(2) L:D: 33:1, Material of screw: 38CrMoALA ,
(3) Auto belt screen changer, the screen is 100mm.
(4) Metering pump: 2 sets
(5) Static mixer: 2 sets.
(6) Spinneret: 2 sets.

2. Cold water tank: 1 set
(1) The tank is made by SS 304 with one light and safety shield.
(2) There are double ceramic roller guiders which are adjustable.

3. First 5-unit roller system:1 set
(1) Motor power: 7.5kw
(2) The steel structure box.

4. Hot water tank:1 set
(1) Overall size: 4000×1300×1100 mm
(2) Heating method: electric heating
(3) Inside of the tank is made by SS 304 with insulating layer.

5. Second 5-unit roller system:1 set
(1) 4 heating roller and working width 1300mm
(2) Standard heater has self-protective and alarm function.
(3) Driving motor and reducer: 15kw

6. Double-layers hot oven tank: 3 sets
(1) Working area: 5000mm L×1350mm W.
Heating power: 35KW×2, the circulating fan: 4Kw×4.
(2) Frequency control speed of blast capacity. Temperature control range: 0-200 degree.

7. Third 5-unit roller system:1 set
(1) Two cooling roller:φ318×1300×3,standard rotary joint.
(2) Driving motor and reducer: 7.5kw

8. 64 spindles winding machine:1 set
(1) Constant tension magnetic disk deviation transmission.
(2) Winding motor: 250w.

9. Waster yarn collector
