1. 70×33 Extruder:2 sets
(1) Main motor power: 18.5KW;
(2) Screw diameter: 70mm;
(3) L:D: 33:1; Material of screw: 38CrMoALA
(4) Metering pump:2 sets, Nozzles: 2 sets
(5) Static mixer: 1 set

2.Cold water tank: 1 set

3. First 7-unit roller system:1 set
(1) Steel roller size: φ270×700×7.

4. Hot water tank: 1 set
(1) Tank length:4000mm
(2) Heating method: by copper heating pipe

5. Dryer system: 1 set

6. Second 7-unit roller system:1 set
(1) Steel roller size: φ350×700×7.
(2) The stretching unit is covered with stainless steel 304

7. Waster yarn collectors system: 1 set

8. Air texturing machines: 24 ends
Each end:
(1) Gas heating barrel:1 sets
(2) Main conveying pipe:1 set,
(3) Heating roller and drive: 2 sets
(4) Tension roller: 2 sets

9. Conveyer device: 6 sets, 4 in 1 unit.

10. 24 spindles winding machine: 1 set
