1. Extruder: 1 set
(1) Screw diameter: 110mm, Rotation speed of screw: 0～72 rpm.
(2) L:D: 33:1, Material of screw: 38CrMoALA, the screw is suitable for PP+PE Virgin.
(3) Filter: Auto screen changer.
(4) Pressure feedback system which can adjust the screw speed automatically.
(5) Material of barrel heater: Far infarad
(6) Metering pump, rotation speed: 0-45 rotation.
(7) Electrical heating round spinneret: 1 set
(8) Ceramic heating rings for spinneret with SS insulating layer. Heating power: 4kw
(9) Spinneret plate: 2 pieces

2. Cold water tank: 1 set
(1) The tank is made by SS 304.
(2) Pushed and pulled in side way, the automatic lifting of tank.
(3) Special designed roller guider to separate the yarn in the tank easily.

3. Drying system:1 set

4. First 7-unit roller system:1 set
(1) Five variable diameter rollers and two steel rollers.
(2) Max drafting force: 1000 daN.
(3) Steel box with accurately grind gear makes the rollers run smoothly.
(4) Built-out oil lubrication system which makes the gears runs steady.
The bearings are from TIMKEN-TWB.

5. First double-layers hot oven tank: 1 set
(1) Heating power: 22.5KW×2
(2) Oven length: 5000 mm
(4) Special design of hot air channel which make the temperature evenly.

6. Second 7-unit roller system:1 set
(1) Six variable diameter rollers and one embossing roller.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady.

7. Winding machine:1 set
(1) Bobbin size : as client’s request

8. Total installation power: 330KW
