1. Extruder: 1 set
(1) Screw diameter: 90 mm, Rotation speed of screw: 0～60 rpm.
(2) L:D: 33:1, Material of screw: 38CrMoALA; The screw is suitable for PP Virgin.
(3) Material of barrel heater: Cast aluminium.
(4) Electric heating round spinneret: 1 set
(5) Ceramic heating rings for spinneret with SS insulating layer make the heat evenly.
(6) Metering pump 100cc/rpm, rotation speed: 0-40 rotation.

2. Cold water tank: 1 set
(1) Material of distributing roller: stainless steel
(2) Side Push-pull model

3. First 7-unit roller system:1 set
(1) Seven roller variable diameter rollers, Five rubber roller.
(2) Steel box with accurately grind gear.
(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.
(4) Built-out oil lubrication system which makes the gears runs steady.

4. Double-layer hot oven tank: 1 set
(1) Fan power: 2.2KW×4 sets
(2) Heating power: 23KW×2
(3) Oven length: 4000 mm
(4) Special design of hot air channel.

5. Second 7-unit roller system:1 set
(1) Seven roller variable diameter rollers, the working width 800mm.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.

6. Single-layer hot oven tank: 1 set
(1) Fan power of each oven: 2.2KW×2 sets
(2) Heating power: 30KW
(3) Oven length: 5000mm
(4) Special design of hot air channel.

7. Third 7-unit roller system:1 set
(1) Seven roller variable diameter rollers, the working width 800mm.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Driving motor and reducer is from Zhejiang Tongli Reducer Co., Ltd.

8. Waster yarn collectors system: 1 set
(1) Torque motor power: 80KG.cm

9. Winding machine:1 set

10. Overall size: 40000×1800×2500mm
