1. Extruder: 1 set
(1) Screw diameter: 80mm, Rotation speed of screw: 0～80 rpm
(2) L:D: 30:1, Material of screw: 38CrMoALA ,
(3) RKC pressure automatic feedback system which can adjust the screw speed automatically.
(4) Material of barrel heater: Cast aluminium with stainless steel insulation layer.
(5) Metering pump, rotation speed: 0-45 rpm.
(6) Round spinneret: 1 set.
(7) Feeding zone should be with sight window and magnetic.

2. Cold water tank: 1 set
(1) The tank is made by SS 304.

3. First 7-unit roller system:1 set
(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.
(2) Steel box with accurately grind gear makes the rollers run smoothly.
(3) Built-out oil lubrication system which makes the gears runs steady. Bearings: TIMKEN-TWB.

4. Overflow type hot water tank: 1 set
(1) Tank size: 4000mm
(2) Electric heating pipe is in the tank.
(3) The tank is made by SS 304 with insulating layer.
(4) Water removal device: 2 sets with suction.

5. Second 7-unit roller system:1 set
(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady. Bearings: TIMKEN-TWB.

6. First double-layer hot oven tank: 1 set
(1) Oven length: 4000 mm
(2) Heating power 23kw×2

7. Third 7-unit roller system:1 set
(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady. Bearings: TIMKEN-TWB.

8. Second double-layer hot oven tank: 1 set
(1) Oven length: 5000 mm
(2) Heating power 23kw×2

9. Fourth 7-unit roller system:1 set
(1) Seven variable diameter rollers made by steel pipe with hard chrome plating.
(2) Steel structure box with accurately grind gear makes the rollers run smoothly.
(3) Built-in oil lubrication system which makes the gears runs steady. Bearings: TIMKEN-TWB.

10. Oil system: 1 set
(1) Frequency control of speed

11. 24 spindles winding machine: 1 set
(1) Spool and bobbin are as sample.
(2) The frame transmission is frequency control, driving motor: 2.2kw
(3) The frame transmit by gear rack

12. Waster yarn collectors: 1 set
(1) Torque motor power: 80KG.cm
