PP Danline Monofilament Extruding Machine For Weaving Fabric 900–6000 Denier
Machine components:
1. Extruder: 1 set
2. Cold water tank: 1 set: 1 set
3. First 7-unit roller system:1 set
4. Double-layers hot oven tank: 2 sets
5. Second 7-unit roller system:1 set
6. Single-layers hot oven tank: 1 set
7. Third 7-unit roller system:1 set
8. Waster yarn collectors: 1 set
9. 150 spindles winding machine: 1 set
Parameter:
| Screw diameter | Φ110mm | ||
| Raw material | PP chips | Filament size | 900-6000D |
Capacity | 250Kg/H | Filament shape | flat |
Screw L:D | 33:1 | Stretching unit | 2-3unit |
Screw material | SACM645 | Winder | Tube |
Max linear speed | 150m/min | Instillation power | 350Kw |
Nozzle holes | 145 | Overall size | 40×2.8m×3m |
